?SA類別超緊密、薄型DC-DC互轉器PICO
分享時：2022-11-09 16:58:16 看：1019
PICO的SA編單的輸出、進行高壓DC-DC轉化器選取超長安小型封裝類型板塊。SA系統轉型器配備率高率和表現出色的過載轉換的功能，能在-25°C至+70°C的高溫超范圍內工作的，也不會會出來電力電氣調額和/或熱管散熱。
表現
超小規模儀器設備機箱
帶中心抽頭的單輸入
防護隔離、非穩壓、3W電機額定效率效率
1500Vdc輸人/打印輸出防護隔離
讀取過壓關畢
極有工作效率率：至87%
嚴厲的環境下調低
低讀取紋波
高輸出/輸出防護
內部的體溫愛護
寬進行溫度表：-25°C至+70°C
應該用
超音波波發生器
雪崩光電產品電子元器件大家庭中的一員-二極管
自動化束擺動
光譜儀學
光電技術檢測器
電解電容進行充電
除靜電光學鏡片
壓電式式元器
成都市立維創展技術是PICO新公司的代銷商。保證進品PICO交流電壓功能引擎、軍工交流電壓功能引擎、高壓低壓變壓器交流電壓功能引擎、小形低壓變壓器、MIL-PRF-21038/27尺寸變電器、電脈沖變電器、400 MHz電力網配電變壓器、MIL-STD-1553電源接口電壓器、音屏電壓器、輸出工作功率電感、微輸出工作功率電感、EMI電感、薄DC-電流主機電源板塊、軍工DC-DC開關電源控制器、磚塊DC-DC電源適配器控制模塊、各類高壓DC-DC、AC-DC電壓信息引擎轉移開關接口、轉移開關開關電壓信息引擎電壓信息引擎轉移開關接口、隔離霜電壓信息引擎轉移開關接口、航空運輸電壓信息引擎轉移開關接口等技能電壓信息引擎轉移開關接口和工作效率轉移器。原裝入口產品入口，產品確保，歡迎圖片網絡咨詢。
詳情介紹要了解PICO交流電源電源模塊請彈框：//www.anchor-appliance.cn/brand/15.html
SERIES 5SA
Standard Models (25°C ambient, Vi, nom and Pout, Max.) |
PICO PART # | INPUT VOLTAGE
(Vdc) | OUTPUT
VOLTAGE | INPUT
VOLTAGE | MAX.
OUTPUT
CURRENT
(mA) | MAX.
OUTPUT
POWER
(W) | LOAD
EFFECT
(%) | EFF.
(%) | OUTPUT
RIPPLE
(%) |
Plug-In | Surface Mount | NOM | RANGE | O.V.
SHDN | NOM
(Vdc) | TOL
(%) | NO
LOAD
(mA) | FULL
LOAD
(mA) |
5SA100 | 5SA100SM | 5 | 4.5...5.5 | 6 | 100 | +/-3 | 65 | 695 | 30.0 | 3 | 5 | 86 | 0.8 |
5SA150 | 5SA150SM | 5 | 4.5...5.5 | 6 | 150 | +/-3 | 66 | 705 | 20.0 | 3 | 6 | 85 | 1.0 |
5SA200 | 5SA200SM | 5 | 4.5...5.5 | 6 | 200 | +/-3 | 65 | 690 | 15.0 | 3 | 8 | 87 | 1.3 |
5SA250 | 5SA250SM | 5 | 4.5...5.5 | 6 | 250 | +/-3 | 67 | 690 | 12.0 | 3 | 7 | 87 | 1.6 |
5SA300 | 5SA300SM | 5 | 4.5...5.5 | 6 | 300 | +/-3 | 66 | 700 | 10.0 | 3 | 6 | 85 | 1.3 |
5SA350 | 5SA350SM | 5 | 4.5...5.5 | 6 | 350 | +/-3 | 67 | 700 | 8.6 | 3 | 6 | 85 | 1.4 |
5SA400 | 5SA400SM | 5 | 4.5...5.5 | 6 | 400 | +/-3 | 56 | 710 | 7.5 | 3 | 5 | 84 | 2.0 |
5SA450 | 5SA450SM | 5 | 4.5...5.5 | 6 | 450 | +/-3 | 57 | 705 | 6.7 | 3 | 5 | 85 | 2.0 |
5SA500 | 5SA500SM | 5 | 4.5...5.5 | 6 | 500 | +/-3 | 59 | 705 | 6.0 | 3 | 2 | 85 | 1.0 |
5SA600 | 5SA600SM | 5 | 4.5...5.5 | 6 | 600 | +/-3 | 70 | 700 | 5.0 | 3 | 6 | 85 | 1.5 |
5SA700 | 5SA700SM | 5 | 4.5...5.5 | 6 | 700 | +/-3 | 76 | 725 | 4.3 | 3 | 5 | 82 | 1.4 |
5SA800 | 5SA800SM | 5 | 4.5...5.5 | 6 | 800 | +/-3 | 83 | 720 | 3.8 | 3 | 3 | 83 | 1.0 |
5SA900 | 5SA900SM | 5 | 4.5...5.5 | 6 | 900 | +/-3 | 90 | 735 | 3.3 | 3 | 5 | 81 | 1.0 |
5SA1000 | 5SA1000SM | 5 | 4.5...5.5 | 6 | 1000 | +/-3 | 95 | 740 | 3.0 | 3 | 5 | 81 | 0.5 |
SERIES 12SA
Standard Models (25°C ambient, Vi, nom and Pout, Max.) |
PICO PART # | INPUT VOLTAGE
(Vdc) | OUTPUT
VOLTAGE | INPUT
CURRENT | MAX.
OUTPUT
CURRENT
(mA) | MAX.
OUTPUT
POWER
(W) | LOAD
EFFECT
(%) | EFF.
(%) | OUTPUT
RIPPLE
(%) |
Plug-In | Surface Mount | NOM TD> | RANGE | O.V.
SHDN | NOM
(Vdc) | TOL
(%) | NO
LOAD
(mA) | FULL
LOAD
(mA) |
12SA100 | 12SA100SM | 12 | 10...14 | 14.5 | 100 | +/-3 | 41 | 290 | 30.0 | 3 | 3 | 86 | 1.0 |
12SA150 | 12SA150SM | 12 | 10...14 | 14.5 | 150 | +/-3 | 41 | 290 | 20.0 | 3 | 6 | 86 | 1.0 |
12SA200 | 12SA200SM | 12 | 10...14 | 14.5 | 200 | +/-3 | 44 | 292 | 15.0 | 3 | 6 | 86 | 1.3 |
12SA250 | 12SA250SM | 12 | 10...14 | 14.5 | 250 | +/-3 | 43 | 302 | 12.0 | 3 | 4.5 | 83 | 1.2 |
12SA300 | 12SA300SM | 12 | 10...14 | 14.5 | 300 | +/-3 | 42 | 298 | 10.0 | 3 | 3.5 | 84 | 0.75 |
12SA350 | 12SA350SM | 12 | 10...14 | 14.5 | 350 | +/-3 | 42 | 300 | 8.6 | 3 | 3.5 | 83 | 1.4 |
12SA400 | 12SA400SM | 12 | 10...14 | 14.5 | 400 | +/-3 | 39 | 295 | 7.5 | 3 | 5 | 85 | 1.5 |
12SA450 | 12SA450SM | 12 | 10...14 | 14.5 | 450 | +/-3 | 39 | 295 | 6.7 | 3 | 6 | 85 | 2.0 |
12SA500 | 12SA500SM | 12 | 10...14 | 14.5 | 500 | +/-3 | 40 | 298 | 6.0 | 3 | 4 | 84 | 1.0 |
12SA600 | 12SA600SM | 12 | 10...14 | 14.5 | 600 | +/-3 | 40 | 300 | 5.0 | 3 | 2 | 83 | 1.0 |
12SA700 | 12SA700SM | 12 | 10...14 | 14.5 | 700 | +/-3 | 45 | 305 | 4.3 | 3 | 4 | 82 | 1.4 |
12SA800 | 12SA800SM | 12 | 10...14 | 14.5 | 800 | +/-3 | 46 | 308 | 3.8 | 3 | 6 | 81 | 1.0 |
12SA900 | 12SA900SM | 12 | 10...14 | 14.5 | 900 | +/-3 | 46 | 310 | 3.3 | 3 | 7 | 81 | 1.0 |
12SA1000 | 12SA1000SM | 12 | 10...14 | 14.5 | 1000 | +/-3 | 47 | 310 | 3.0 | 3 | 8 | 81 | 0.75 |
SERIES 24SA
Standard Models (25°C ambient, Vi, nom and Pout, Max.) |
PICO PART # | INPUT VOLTAGE
(Vdc) | OUTPUT
VOLTAGE | INPUT
CURRENT | MAX.
OUTPUT
CURRENT
(mA) | MAX.
OUTPUT
POWER
(W) | LOAD
EFFECT
(%) | EFF.
(%) | OUTPUT
RIPPLE
(%) |
Plug-In | Surface Mount | NOM | RANGE | O.V.
SHDN | NOM
(Vdc) | TOL
(%) | NO
LOAD
(mA) | FULL
LOAD
(mA) |
24SA100 | 24SA100SM | 24 | 21...27 | 28 | 100 | +/-3 | 19 | 145 | 30.0 | 3 | 6 | 86 | 1.0 |
24SA150 | 24SA150SM | 24 | 21...27 | 28 | 150 | +/-3 | 20 | 145 | 20.0 | 3 | 6 | 86 | 1.0 |
24SA200 | 24SA200SM | 24 | 21...27 | 28 | 200 | +/-3 | 20 | 150 | 15.0 | 3 | 6 | 83 | 1.3 |
24SA250 | 24SA250SM | 24 | 21...27 | 28 | 250 | +/-3 | 21 | 153 | 12.0 | 3 | 5 | 82 | 1.2 |
24SA300 | 24SA300SM | 24 | 21...27 | 28 | 300 | +/-3 | 21 | 155 | 10.0 | 3 | 5 | 81 | 1.0 |
24SA350 | 24SA350SM | 24 | 21...27 | 28 | 350 | +/-3 | 22 | 156 | 8.6 | 3 | 4 | 80 | 1.4 |
24SA400 | 24SA400SM | 24 | 21...27 | 28 | 400 | +/-3 | 18 | 147 | 7.5 | 3 | 5 | 85 | 1.5 |
24SA450 | 24SA450SM | 24 | 21...27 | 28 | 450 | +/-3 | 19 | 148 | 6.7 | 3 | 6 | 84 | 2.0 |
24SA500 | 24SA500SM | 24 | 21...27 | 28 | 500 | +/-3 | 20 | 148 | 6.0 | 3 | 4 | 84 | 1.0 |
24SA600 | 24SA600SM | 24 | 21...27 | 28 | 600 | +/-3 | 20 | 148 | 5.0 | 3 | 7 | 84 | 1.2 |
24SA700 | 24SA700SM | 24 | 21...27 | 28 | 700 | +/-3 | 23 | 149 | 4.3 | 3 | 4 | 84 | 1.4 |
24SA800 | 24SA800SM | 24 | 21...27 | 28 | 800 | +/-3 | 23 | 150 | 3.8 | 3 | 6 | 83 | 1.0 |
24SA900 | 24SA900SM | 24 | 21...27 | 28 | 900 | +/-3 | 24 | 150 | 3.3 | 3 | 7 | 83 | 1.0 |
24SA1000 | 24SA1000SM | 24 | 21...27 | 28 | 1000 | +/-3 | 24 | 150 | 3.0 | 3 | 6 | 83 | 0.75 |
SERIES 28SA
Standard Models (25°C ambient, Vi, nom and Pout, Max.) |
PICO PART | INPUT VOLTAGE
(Vdc) | OUTPUT
VOLTAGE | INPUT
CURRENT | MAX.
OUTPUT
CURRENT
(mA) | MAX.
OUTPUT
POWER
(W) | LOAD
EFFECT
(%) | EFF.
(%) | OUTPUT
RIPPLE
(%) |
Plug-In | Surface Mount | NOM | RANGE | O.V.
SHDN | NOM
(Vdc) | TOL
(%) | NO
LOAD
(mA) | FULL
LOAD
(mA) |
28SA100 | 28SA100SM | 28 | 25...30 | 31 | 100 | +/-3 | 20 | 129 | 30.0 | 3 | 6 | 83 | 1.0 |
28SA150 | 28SA150SM | 28 | 25...30 | 31 | 150 | +/-3 | 20 | 129 | 20.0 | 3 | 6 | 83 | 1.0 |
28SA200 | 28SA200SM | 28 | 25...30 | 31 | 200 | +/-3 | 21 | 132 | 15.0 | 3 | 6 | 81 | 1.3 |
28SA250 | 28SA250SM | 28 | 25...30 | 31 | 250 | +/-3 | 21 | 133 | 12.0 | 3 | 5 | 81 | 1.2 |
28SA300 | 28SA300SM | 28 | 25...30 | 31 | 300 | +/-3 | 22 | 133 | 10.0 | 3 | 6 | 81 | 1.0 |
28SA350 | 28SA350SM | 28 | 25...30 | 31 | 350 | +/-3 | 22 | 134 | 8.6 | 3 | 4 | 80 | 1.4 |
28SA400 | 28SA400SM | 28 | 25...30 | 31 | 400 | +/-3 | 18 | 127 | 7.5 | 3 | 5 | 84 | 1.5 |
28SA450 | 28SA450SM | 28 | 25...30 | 31 | 450 | +/-3 | 19 | 128 | 6.7 | 3 | 6 | 84 | 2.0 |
28SA500 | 28SA500SM | 28 | 25...30 | 31 | 500 | +/-3 | 20 | 129 | 6.0 | 3 | 4 | 83 | 1.0 |
28SA600 | 28SA600SM | 28 | 25...30 | 31 | 600 | +/-3 | 20 | 130 | 5.0 | 3 | 5 | 82 | 1.5 |
28SA700 | 28SA700SM | 28 | 25...30 | 31 | 700 | +/-3 | 23 | 127 | 4.3 | 3 | 4 | 84 | 1.4 |
28SA800 | 28SA800SM | 28 | 25...30 | 31 | 800 | +/-3 | 23 | 127 | 3.8 | 3 | 6 | 84 | 1.0 |
28SA900 | 28SA900SM | 28 | 25...30 | 31 | 900 | +/-3 | 24 | 128 | 3.3 | 3 | 7 | 84 | 1.0 |
28SA1000 | 28SA1000SM | 28 | 25...30 | 31 | 1000 | +/-3 | 24 | 128 | 3.0 | 3 | 6 | 84 | 1.0 |
